TDA7492P Bluetooth Amplifier Board CSR4.0 Audio Receiver Digital Stereo Amp Module

TDA7492P digital amplifier board with CSR4.0 Bluetooth audio receiver. Supports wireless Bluetooth and wired audio input. 2×50W stereo output, 90% efficiency. Onboard volume control, indicator LED. Ideal for DIY Bluetooth speakers, TV soundbars, car audio, home theater

TDA7492P Bluetooth Amplifier Board Application features:

◆ Amplifier Chip
TDA7492P (Class D digital stereo amplifier)

◆ Bluetooth Chip
CSR4.0 (CSR original, A2DP protocol support)

◆ Output Power

• 2×50W stereo (4Ω load, 24V supply)

• 2×30W stereo (8Ω load, 24V supply)

◆ Amplifier Class
Class D (digital amplifier)

◆ Efficiency
Up to 90%

◆ Bluetooth Version
4.0 (backward compatible, A2DP/AVRCP support)

◆ Bluetooth Range
~10 meters (open area)

◆ Audio Input Methods

• Wireless Bluetooth input

• Wired AUX input (3.5mm)

◆ Auto Input Switching
AUX priority (Bluetooth auto disconnects when AUX is plugged in)

◆ Operating Voltage
DC 12V ~ 24V (24V recommended)

◆ Load Impedance
4Ω ~ 8Ω

◆ Onboard Features

• Volume control potentiometer

• Power indicator LED (blue/red)

• Bluetooth status LED (blinking/solid)

◆ Interfaces

• Bluetooth antenna

• 3.5mm AUX input jack

• Speaker terminal blocks

• Power terminal blocks

◆ Typical Applications

• DIY Bluetooth speakers

• TV soundbar upgrade

• Car audio system upgrade

• Home theater system

• Computer speaker modification

• Outdoor portable speakers

• Background music system

◆ Key Advantages

• Bluetooth + amplifier 2-in-1

• CSR original Bluetooth chip for good audio quality

• AUX and Bluetooth auto-switching

• Class D amplifier (no large heatsink needed)

• Wide voltage input (12-24V)

• Onboard volume control

• Plug-and-play, easy to install

Why Choose QIXINWEI

Years of experience in the electronics industry. Trusted by global customers.

Massive In-Stock Inventory – Ready to ship promptly

BOM Matching Service – One-stop solution, save time

PCBA Customization – Professional engineering team creates tailor-made solutions based on your needs

Cost-Effective & Efficient – Better channel, better cost

A dedicated team makes your procurement smoother.

Contact us for BOM quotes or PCBA inquiries

Notes : Since the prices of the electronic components are unstable, the prices we show are for reference only. Please confirm the recent prices with us before ordering!

Lead Time : Usually, your parcel will be arranged within 7 days after finishing payment. We'll send it more quickly if it's an urgent order. Thanks for your understanding!

Quantity(Pieces)	1 ~ 30000	30001 ~ 300000	> 300000
Est. Time(days)	5	7	To be negotiated

FAQ:

1. What is the TDA7492P Bluetooth amplifier board and its key specifications?
   This is a 2.0 stereo Class‑D audio amplifier module built around the STMicroelectronics TDA7492P chip and a CSR4.0 Bluetooth receiver. It delivers efficient, high‑quality wireless audio amplification. Key specifications: operating voltage 10 V – 26 V DC (recommended 12 V – 24 V), output power up to 2 × 50 W into 6 Ω (at 25 V, 1% THD+N) or 2 × 25 W into 8 Ω (at 20 V), Bluetooth 4.0 (supports A2DP, AVRCP, HSP/HFP), a 3.5 mm AUX line‑in, and an on‑board volume potentiometer. The board includes a PCB heatsink and over‑current/thermal protection. It is commonly used for DIY Bluetooth speakers, soundbars, and portable audio systems where wireless connectivity and efficient power are needed.

2. What Bluetooth version does the board use, and what is the typical range?
   The board integrates a CSR8635 or similar CSR4.0 Bluetooth module, supporting Bluetooth 4.0 with backward compatibility to 2.1/3.0. It supports A2DP for high‑quality stereo audio streaming. The typical wireless range is 10 m (33 ft) in open air, which is standard for Class 2 Bluetooth devices. Walls and obstacles will reduce this range. The module automatically enters pairing mode when powered on (indicated by a flashing LED) and reconnects to previously paired devices.

3. How do I connect power, speakers, and audio sources to the TDA7492P board?
   Wiring is straightforward. Power: connect a DC supply (12 V – 24 V, at least 3 A – 5 A for full power) to the screw terminals labelled VCC (+) and GND (-). Speakers: connect the left speaker to L+ and L‑, and the right speaker to R+ and R‑. The board supports 4 Ω – 8 Ω speakers; 6 Ω – 8 Ω is recommended for continuous high‑power use. Audio input: use the 3.5 mm AUX jack for wired sources, or pair via Bluetooth. The on‑board potentiometer controls the volume for both Bluetooth and AUX. The board automatically switches to AUX when a cable is plugged in.

4. What is the maximum output power, and how does it depend on the power supply?
   The TDA7492P can deliver up to 2 × 50 W into 6 Ω at 25 V supply with 1% THD+N. For 8 Ω speakers, the maximum is about 2 × 30 W at 25 V. At a common 12 V supply, you can expect approximately 2 × 15 W (6 Ω) or 2 × 10 W (8 Ω). The actual output depends on the power supply's current capability and the speaker impedance. To achieve the full 50 W per channel, a 24 V / 5 A or higher supply is necessary. The built‑in DC protection shuts down the chip if the voltage exceeds 30 V.

5. How does the TDA7492P compare to the TPA3116D2 or TPA3118?
   All three are popular Class‑D stereo amplifier chips. The TDA7492P typically offers slightly higher output power at 25 V (up to 2×50W into 6Ω) compared to the TPA3116/3118 (2×50W into 4Ω at 24V). The TPA3116 has a higher maximum voltage (30 V vs. 26 V for TDA7492P) and slightly better efficiency at high power. The TDA7492P uses a different output filter topology that can sometimes produce cleaner sound with certain speakers. In practice, both are excellent. The TDA7492P boards often include an integrated Bluetooth module and heatsink, making them a convenient all‑in‑one solution for wireless speakers.

6. Does the TDA7492P board require an additional heatsink? How hot does it get?
   The TDA7492P chip uses the PCB copper plane as a heat spreader, and most boards come with a pre‑soldered aluminium heatsink on the chip. For moderate power levels (up to 20 W – 25 W per channel), this is adequate. For continuous high‑power operation near 2 × 50 W, especially with 6 Ω or lower impedance speakers, the chip can become very hot. It is recommended to ensure good ventilation and optionally add a small fan. The built‑in thermal protection will shut down the amplifier if the die temperature exceeds about 150 °C, preventing permanent damage.

7. How do I pair my phone or computer with the Bluetooth module?
   Power on the amplifier. The Bluetooth module enters pairing mode automatically, indicated by a rapidly flashing blue LED. On your phone or computer, open Bluetooth settings and search for new devices. The module usually appears as “CSR8635”, “BT Speaker”, or a similar generic name. Click to connect. Once paired, the LED will flash slowly or stay solid. The module supports auto‑reconnect — it will automatically connect to the last paired device when powered on. To pair a new device, you may need to disconnect the current one or press a small reset/play button on the Bluetooth module.

8. What protection features does the TDA7492P chip include?
   The TDA7492P provides robust protection: over‑current protection (OCP) on each channel, over‑temperature protection (OTP) with automatic recovery, under‑voltage lockout (UVLO) to prevent malfunction at low voltage, and DC offset detection on the speaker outputs (protecting speakers from damaging DC). It also features a standby mode that reduces power consumption when no audio is playing, and a mute function for pop‑free start‑up. The Bluetooth module has its own independent power regulation, ensuring stable operation.

9. Can I use this board in a battery‑powered portable speaker?
   Yes, the wide voltage range of 10 V – 26 V makes it suitable for battery power. A 12 V lead‑acid battery or a 3S or 4S Li‑Ion/Li‑Po pack (11.1 V – 14.8 V) works well. At 12 V, the power output is modest but still sufficient for a loud portable speaker. For longer runtime and higher power, a 5S or 6S Li‑Ion pack (18.5 V – 22.2 V) can be used, as long as the voltage does not exceed 26 V. Remember to add a fuse and a low‑voltage cutoff circuit to protect the battery from over‑discharge. The amplifier's efficiency (> 85 %) helps extend battery life.

10. What are the most typical applications for the TDA7492P Bluetooth amplifier board?
    It is widely used in DIY Bluetooth speakers, portable boomboxes, wireless soundbars, home audio amplifiers, garage/workshop speakers, and retro radio upgrades. Its combination of a powerful amplifier, integrated Bluetooth, and simple power requirements makes it a favourite for hobbyists who want to build a high‑quality wireless speaker with minimal components. The board can also be used in industrial or educational audio demonstration systems.
