LAUNCHXL-F28379D Dual-Core Dev Board C2000 Delfino Real-Time Control MCU

LAUNCHXL-F28379D is TI's low-cost C2000 Delfino LaunchPad with TMS320F28379D dual-core C28x @200MHz, 1MB Flash, dual CLAs, 16/12-bit ADCs, HRPWM, eQEP. Onboard isolated XDS100v2 JTAG. For motor drives, digital power, PV inverters, servo control

Core Processor

◆ Main Chip
TMS320F28379D (C2000 Delfino series)

◆ Processor Cores
Dual-core C28x 32-bit CPUs, each @200MHz

◆ Co-processor
Dual Control Law Accelerators (CLA) operating independently of main CPU

◆ Floating Point Unit
IEEE 754 single-precision floating point support

◆ Architecture
Unified RAM architecture, inter-core communication via shared memory

Memory Specifications

◆ Flash
1MB (with ECC error correction)

◆ SRAM
Shared memory + dedicated local RAM per core

◆ Security
Dual-zone security ROM for code protection

Analog Peripherals

◆ ADC

• 4x 16-bit ADCs (multiple channels)

• 3x 12-bit ADCs (high conversion rate)

• Differential input support

◆ DAC
3x 12-bit buffered DAC outputs

◆ Comparators
7 windowed comparators

◆ Delta-Sigma Filters
4 Sinc filters for isolated current/voltage measurement

High-Resolution PWM

◆ Module Configuration
8 enhanced PWM modules (ePWM)

◆ Resolution
Up to 150ps high-resolution PWM (HRPWM)

◆ Synchronization
Sub-nanosecond synchronization across all outputs

◆ Advanced Features

• Dead-band configuration

• PWM chopping

• Trip-zone inputs for fault protection

Position Management Interfaces

◆ Encoder Interfaces

• 2 enhanced Quadrature Encoder Pulse (eQEP) modules

• Absolute encoder support

• Resolver and SINCOS sensor support

◆ Capture Modules
6 enhanced Capture (eCAP) modules

◆ Performance
Resolution <0.005°/count, speed >10,000 rpm

Communication Interfaces

◆ CAN
Isolated CAN transceiver connector (onboard)

◆ Other Interfaces

• 3x I2C buses

• 3x SPI buses

• 3x UART serial ports

• McBSP multi-channel buffered serial port

◆ Expansion
4x 20-pin BoosterPack headers, dual BoosterPack support

Onboard Debug Features

◆ Debug Probe
XDS100v2 isolated JTAG debugger (USB connected)

◆ Debug Capabilities

• Real-time in-system programming

• Real-time debugging (CCS graphical waveform display)

• Flash programming

◆ USB Interface
Provides UART serial connection to host PC

◆ Dual-Core Debug
CCS supports simultaneous debugging of CPU1 and CPU2

User Interface

◆ Programmable Buttons
User-defined buttons

◆ Programmable LEDs
GPIO-controlled user LEDs

◆ Reset Button
Onboard reset switch

◆ Status Indicators
Power LED (D1), user LEDs (D9/D10)

Boot Options

◆ Boot Mode Switch
4-position DIP switch (S1) for boot mode configuration

◆ Boot Modes

• Emulation boot mode (when JTAG debugger connected)

• Standalone boot mode (configured via GPIO pins)

Power and Isolation

◆ Power Supply
USB powered (via Mini USB-B)

◆ Electrical Isolation
Isolation jumpers (JP1/JP2/JP3) for optional isolated power

◆ External Power
BoosterPack header power input (when isolation jumpers removed)

Development Environment

◆ IDE Support

• Code Composer Studio (free download)

• MathWorks MATLAB/Simulink embedded target support

◆ Software Package
C2000Ware (device drivers and example projects)

◆ Platform Support

• DesignDRIVE (motor drive development platform)

• powerSUITE (digital power software suite)

◆ Third-Party Support
solidThinking Embed support

Compatibility and Expansion

◆ BoosterPack Compatible
Supports two BoosterPack plug-in modules

◆ Package Compatibility
Superset device allows migration to lower pin-count F2837x devices

◆ Encoder Connectors
Two dedicated encoder interface connectors

Applications

◆ Motor Control

• Servo drives (torque ripple <1.5%)

• AC induction motor control

• BLDC motor control

• Collaborative robot joint actuation

◆ Digital Power

• Inverter control

• Converter control

• Digital power management

◆ Industrial Drives

• DesignDRIVE platform development

• CNC spindle drives

• Industrial automation

◆ Real-Time Signal Processing

• Sensor data acquisition

• Closed-loop control algorithms

• Hardware-in-the-Loop (HIL) testing

◆ Academic Research

• Control algorithm validation

• Embedded real-time systems education

• Laboratory prototyping
